Truck livery concept A

The Navy Flagship

Full navy curtains carry the wordmark, one delivery message, a red price device and the contact line. No photography in this concept: the type and a clean waterline graphic do all the work.

Isuzu FSR 120-240, Big Rigs curtainsiderCurtains 7,400 x 2,700 mm per side
Rear panel 2,360 x 2,680 mm
Nose strip 2,200 x 400 mm
Artboards at 1:10 scale, drawn 1.6x for screen Overlays: buckle zone, buckle positions, pleat interval, cab end, rear lift hardware
Artboard 1

Driver side curtain

7,400 x 2,700 mm
Reading order starts at the cab end: wordmark first, then the message, then the price device in the rear third. Contact line sits in aqua above the buckle zone. Bottom 350 mm is background only.
Aqua Pulse Spas wordmark, white
Premium spas, delivered door to door
anywhere in Australia.
SPAS FROM$4,999
aquapulsespas.com.au(07) 3208 4625
BUCKLE ZONE 350 mm: background only, no text or logos
Curtain pleats at roughly 500 mm: no fine detail, min cap height 120 mm
CAB END
Cab end on the left. All copy reads left to right from the cab.
Artboard 2

Passenger side curtain, mirrored composition

7,400 x 2,700 mm
Same five elements re-set as a mirror of the driver side, so the wordmark still leads from the cab end. This is a mirrored layout, not flipped artwork: all type reads normally.
Aqua Pulse Spas wordmark, white
Premium spas, delivered door to door
anywhere in Australia.
SPAS FROM$4,999
aquapulsespas.com.au(07) 3208 4625
BUCKLE ZONE 350 mm: background only, no text or logos
Curtain pleats at roughly 500 mm: no fine detail, min cap height 120 mm
CAB END
Cab end on the right. Wordmark stays at the cab end, price device moves to the tail third.
Artboard 3

Rear doors and tailgate

2,360 x 2,680 mm
Audience is a driver stopped 2 to 5 metres behind at lights, so this is the only panel that carries the QR code. All critical content sits inside the middle 2,000 mm, clear of the column lift hardware. QR is 500 mm with a 60 mm quiet zone on a white card.
Aqua Pulse Spas wordmark, white
SPAS FROM$4,999
QR code to the spa range
Scan for the full spa rangeaquapulsespas.com.au
(07) 3208 4625
LIFT
LIFT
Hardware keep-out is 180 mm each side. Rigid panel, so finer sizes are safe here.
Artboard 4

Nose cone brand strip

2,200 x 400 mm
One slim navy strip above the cab: white wordmark only, centred.
Aqua Pulse Spas wordmark, white
Faces forward traffic. Nothing else competes on this surface.

How it will really look

The driver side artwork at road distances. Judge it at these sizes, not at artboard size: if the message and price do not land here, they do not land on the highway.

About 40 m, passing traffic
About 60 m, oncoming lane

Production notes

Material

UV-stabilised PVC curtain print (reinforced ripstop curtain stock) for both sides, rigid-panel wrap or paint-match for the rear doors and nose cone. Confirm substrate and print partner with Big Rigs before artwork handover.

Vector logo required

The logo files on this page are 584 x 90 raster PNGs and are concept-grade only. The client's vector logo (AI, EPS or SVG) is required before any print artwork is produced. Do not scale the PNG to print size.

Fonts

Bricolage Grotesque and Assistant, as used across the APS web build. Outline all type to paths before handover so the printer never substitutes fonts.

Colour matching

Match navy #000e2e, brand blue #1B75BC and price red #E11D2A to PMS and CMYK under the printer's profile. The navy prints near black on PVC, so request a drawdown or proof panel before the full run.

Bleed and keep-away

50 mm bleed on all edges. The bottom 350 mm of each curtain is the load-restraint buckle zone (buckles every 500 mm): background colour and the waterline graphic only, no text, logos or faces. Keep all type at least 120 mm cap height, phone digits 250 mm or larger, headline letters 400 mm or larger.

QR code

Rear doors only, never on the curtains (pleating distorts codes). Minimum 400 x 400 mm printed, shown here at 500 mm with a 60 mm quiet zone on a white card. The code links to the spa range with utm_source=truck tracking. Test a printed proof at 3 m before the full run.

Mirrored sides

The passenger side is a re-set mirrored composition, not flipped artwork. Two separate print files are required, one per side.

Photography

This concept uses no photography. If a photographic variant is chosen instead, final imagery must come from the new professional shoot currently in edit, not from the existing raw footage.

Pricing decisionThe printed price

$4,999 is correct today (verified live). A printed price is a reprint liability if pricing changes. Decision for Aaron/client: keep price (max impact) or replace with "Australia's best value premium spas" style claim-free device.
